Integrated Hydraulics伊顿平衡阀406AA00005A 1CE30F35S5样本

介绍说明

1CE30 为螺纹插装式的标准平衡阀,它有三路油口,可通过外部先导进行控制。

工作原理

平衡阀中,压力油能从 2 (阀口)自由流入 1 (负载口,并阻止液压油的反向流动。当液压油有反向运动(1 口流2 口)趋势时,只有当达到预设压力(至少高于 1.3倍的最大负载),或者 3 口(先导油口)建立一定压力时,液压油才能顺利流过。

额定参数与技术规格

相关参数基于:油温 = 40℃ 粘度 = 40 cSt

额定流量30 l/min (8 US GPM)

最大压力:最大负载平衡压力:270 bar(4000 psi)

      溢流阀设置 350 bar(5000 psi)

插件材质:工作部件为磨削加工淬火处理的钢(外表面镀锌)

阀体材料铝(耐压 210bar);钢(耐压 350bar,编号后缀加”377”

安装位置:没有限制

插装孔型编号插件拧紧扭矩重量:45 Nm (33 lbs ft)

密封件号:SK395(丁腈橡胶) SK395V(氟橡胶

系统油液清洁等级工作温度:BS5540/4 18/13 级;( 通常 25 微米)


内泄量:额定 0.3 ml/min (5 滴)
标称粘度范围:5 到 500 cSt


1CE SERIES OVERCENTRE VALVE PILOT ASSISTED RELIEF WITH CHECK 1CE30F35S5 EATON VICKERS DANFOSSS
Shanghai D&C Hydraulic Fluid Power.
Room 1005,NO.4,1388 lane,Yungu Road,Jiading,Shanghai
Tel:86-21-59100212
Fax:86-21-59100212
Mobile:86-18701882843
Website:www.dchydraulic.com
Mail:infoshdc@126.com




APPLICATION
Overcentre valves give static and dynamic control of loads by regulating the flow into and out of hydraulic actuators. When installed close to or within an actuator, the overcentre valve will stop runaway in the event of hose burst and if open centre directional
control valves are used, will allow thermal expansion relief of the hydraulic fluid.The overcentre cartridge is ideal for mounting directly into a cavity machined in the body of the cylinder, motor or rotary actuator. The cartridge can also be mounted directly to the ports via a specifically machined body as part of a Hydraulic Integrated Circuit or single unit, or
contained within one of our standard line bodies. Single overcentre valves are normally used when the load is unidirectional, for example an aerial platform or crane and dual overcentre valves are used for controlling loads in both directional for motor applications or for cylinders going over centre.


OPERATION
The check section allows free flow into the actuator then holds and locks the load against movement. The pilot assisted relief valve section will give controlled movement when pliot pressure is applied. The relief section is normally set to open at a pressure at least 1.3 times the maximum load induced pressure but the
pressure required to open the valve and allow movement depends on the pilot ratio of the valve. For optimisation of load control and energy usage, a choice of pilot ratios is available. The pressure required to open the valve and start actuator movement can be calculated as follows:
Pilot Pressure = (Relief Setting) - (Load Pressure)
Pilot Ratio
PILOT RATIOS
2.5:1 Best suited for extremely unstable applications such as long booms or flexible frameworks.
5:1 Best suited for applications where load varies(Standard) and machine structure can induce instability
10:1 Best suited for applications where the load remains relatively constant.
FEATURES
Cartridge is economical and fits simple cavity. Allows quick, easy field service - reduces down time. Directly interchangeable with 30 litres/min pilot check valve.
SPECIFICATIONS


Rated Flow :30 litres/min (8 US GPM)
Cartridge Material:Working parts hardened and ground steel. External surfaces zinc plated
Max Setting:Max Load Induced
                     Pressure: 270 bar (4000 psi)
                     Relief Setting:350 bar (5000 psi)
Body Material:Standard aluminium (up to 210 bar*)Add suffix ‘377’ for steel option
Mounting Position:Unrestricted
Cavity Number:A6610
Torque Cartridge into Cavity :45 Nm (33 lbs ft)
Weight:1CE30 0.15 kg (0.33 lbs)
              1CE35 0.41 kg (0.90 lbs)
              1CEE34 0.90 kg (1.98 lbs)
Seal Kit Number:SK395 (Nitrile) SK395V (Viton)
Operating Temp:-20°C to +90°C
Leakage :0.3 millilitres/min nominal (5 dpm)
Nominal Viscosity Range:5 to 500 cSt


Basic Code
1CE30 = Cartridge Only
1CE35 = Cartridge and Body
1CEE34 = Cartridges and Dual Body


Adjustment Means
F = Screw Adjustment
N = Fixed - State pressure setting required For fixed versions add setting in 10 bar increments to end of part number. Subject to a + -10% tolerance.


Port Sizes - Bodied Valves Only
3W = 3/8” BSP Valve & Cyl Port. 1/4” BSP Pilot Port
6T = 3/8” SAE Valve & Cyl Port. 1/4” SAE Pilot Port
8T = 1/2” SAE Valve & Cyl Port. 1/4” SAE Pilot Port


Seals
S = Nitrile (For use with most industrial hydraulic oils)
SV = Viton (For high temperature and most special fluid applications)


Pressure Range @ 4.8 l/min
20 = (2.5:1 and 5:1): 70-210 bar. Std setting 100 bar
(10:1): 100-210 bar. Std setting 100 bar
35 = (2.5:1 and 5:1): 100-350 bar. Std setting 210 bar
(10:1): 120-350 bar. Std setting 210 bar


Pilot Ratio
2 = 2.5:1
5 = 5:1 (Standard)


SINGLE VALVE BASIC CODE: 1CE35  3/8” 1/2” PORTS
Body ONLY part numbers
BSP, aluminium 3/8” B6743
SAE, aluminium 3/8” B10536 1/2” B7884
BSP, steel 3/8” B12823
SAE, steel 1/2” B11811


DUAL VALVE  3/8” 1/2” PORTS BASIC CODE: 1CEE34(INTERNALLY CROSSED PILOTED)
BSP, aluminium 3/8” B6836
SAE, aluminium 3/8” B10805 1/2” B30237
BSP, steel 3/8” B13803
SAE, steel 1/2” B11812




Eaton Vickers by Danfoss 406AA00005A Screw-in Cartridge Valves - 1CE30; Eaton Screw-in Cartridge Valve; Overcenter; Standard
Model Code: 1CE30-F-35S5
Feature Code Description
SERIES 1CE30 OVER CENTER VALVE -PILOT ASSISTED RELIEF WITH CHECK VALVE-30 L/MIN - CATRIDGE ONLY
ADJUSTMENT -F SCREW ADJUSTMENT
PORT SIZE _ CARTRIDGE ONLY
PRESSURE RANGE -35 100-350 BAR (2.5;1, 5;1) ; 120-350 BAR(10;1);STD SET - 210 BAR
SEAL S NITRILE (FOR USE WITH MOST INDUSTRIAL HYDRAULIC OILS)
PILOT RATIO 5 5;1
BODY MATERIAL _ NONE
SPECIAL FEATURE _ NO SPECIAL FEATURES
SPECIAL PRESSURE SETTING * SPECIAL PRESSURE SETTING IN BAR




GENERAL SPECIFICATIONS
PRODUCT NAME
Vickers by Danfoss 1CE30 Series Motion Control Valves
CATALOG NUMBER:406AA00005A
MODEL CODE:1CE30-F-35S-5
PRODUCT LENGTH/DEPTH:3.52 in
PRODUCT HEIGHT:1 in
PRODUCT WIDTH:1 in
PRODUCT WEIGHT:.33 lb
WARRANTY:Hydraulics Warranty
PRODUCT SPECIFICATIONS
INSTALLATION TYPE:Screw-in Cartridge
PORT SIZE:None
ADJUSTMENT TYPE:Screw
OPERATION:Pilot Operated
PRESSURE RATING:350 bar
NUMBER OF HOUSING PORTS:3
SEAL TYPE:Buna-N
MAXIMUM LOAD INDUCED PRESSURE
270 bar
CAVITY:A6610
NUMBER OF VALVE PORTS:3
PORT TYPE:Cartridge Only
STYLE:Pilot assisted relief with check
OPERATING TEMPERATURE:-30°C to +90°C
MAXIMUM RELIEF PRESSURE:350 bar
LEAKAGE:0.25 cc/min
SPECIAL FEATURES:None
MINIMUM PILOT ADJUSTMENT:40.5 bar
FLOW RATE:30 l/min
MAXIMUM PILOT ADJUSTMENT:49.5 bar
HOUSING:No
FLUID COMPATIBILITY:MIL–H–5606, SAE 10, SAE 20, etc
RECOMMENDED FILTRATION LEVEL:18/16/13
FUNCTION:Overcenter Valve
VALVE MATERIAL:Steel
APPLICATION:Harvesters, refuse haulers, mobile and industrial applications
PILOT RATIO:5:1


Shanghai D&C Hydraulic Fluid Power.
Room 1005,NO.4,1388 lane,Yungu Road,Jiading,Shanghai
Tel:86-21-59100212
Fax:86-21-59100212
Mobile:86-18701882843
Website:www.dchydraulic.com
Mail:infoshdc@126.com
EATON VICKERS DANFOSSS overcenter Valve 406AA00584A 1CE30F10SV2
EATON VICKERS DANFOSSS overcenter Valve 406AA00353A 1CE30F20S10
EATON VICKERS DANFOSSS overcenter Valve 406AA00588A 1CE30F20S2
EATON VICKERS DANFOSSS overcenter Valve 406AA00089A 1CE30F20S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00590A 1CE30F20SV10
EATON VICKERS DANFOSSS overcenter Valve 406AA00352A 1CE30F20SV5
EATON VICKERS DANFOSSS overcenter Valve 406AA00006A 1CE30F35S10
EATON VICKERS DANFOSSS overcenter Valve 406AA00004A 1CE30F35S2
EATON VICKERS DANFOSSS overcenter Valve 406AA00005A 1CE30F35S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00640A 1CE30F35SV10
EATON VICKERS DANFOSSS overcenter Valve 406AA00642A 1CE30F35SV2
EATON VICKERS DANFOSSS overcenter Valve 406AA00134A 1CE30F35SV5
EATON VICKERS DANFOSSS overcenter Valve 406AA00648A 1CE30-F-7S-10
EATON VICKERS DANFOSSS overcenter Valve 406AA00657A 1CE30G35S5
EATON VICKERS DANFOSSS overcenter Valve 406AA03172A 1CE30G35SV5
EATON VICKERS DANFOSSS overcenter Valve 406AA00672A 1CE30N13S2
EATON VICKERS DANFOSSS overcenter Valve 406AA02741A 1CE30N16S25
EATON VICKERS DANFOSSS overcenter Valve 406AA00673A 1CE30N16S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00674A 1CE30N18S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00095A 1CE30N20S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00137A 1CE30N21S2
EATON VICKERS DANFOSSS overcenter Valve 406AA00138A 1CE30N21S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00139A 1CE30N23S10
EATON VICKERS DANFOSSS overcenter Valve 406AA00096A 1CE30N23S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00140A 1CE30-N-24.2S-5
EATON VICKERS DANFOSSS overcenter Valve 406AA00685A 1CE30-N-24.5S-2
EATON VICKERS DANFOSSS overcenter Valve 406AA02742A 1CE30N24S10
EATON VICKERS DANFOSSS overcenter Valve 406AA00142A 1CE30N25S2
EATON VICKERS DANFOSSS overcenter Valve 406AA00097A 1CE30N25S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00688A 1CE30N25SV2
EATON VICKERS DANFOSSS overcenter Valve 406AA00379A 1CE30N27S2
EATON VICKERS DANFOSSS overcenter Valve 406AA00144A 1CE30N27S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00145A 1CE30N28S10
EATON VICKERS DANFOSSS overcenter Valve 406AA03031A 1CE30N30S2
EATON VICKERS DANFOSSS overcenter Valve 406AA00147A 1CE30N30S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00690A 1CE30N32S10
EATON VICKERS DANFOSSS overcenter Valve 406AA00691A 1CE30N35S10
EATON VICKERS DANFOSSS overcenter Valve 406AA00363A 1CE30N35S5
EATON VICKERS DANFOSSS overcenter Valve 406AA00695A 1CE30N35SV10
EATON VICKERS DANFOSSS overcenter Valve 406AA03042A 1CE30N38S10
EATON VICKERS DANFOSSS overcenter Valve 406AA00699A 1CE30N5S2
EATON VICKERS DANFOSSS overcenter Valve 406AA00148A 1CE30-N-7.5S-5
EATON VICKERS DANFOSSS overcenter Valve 406AA00149A 1CE30N8S5









1CE30 - Overcenter valve
Pilot assisted relief with check
30L/min (8 USgpm) • 270 bar (4000 psi)
Operation:
The check section allows The check section allows free flow into the actuator then holds and locks the load against movement. The pilot assisted relief valve section will give controlled movement when pilot pressure is applied. The relief section is normally set to open at a pressure at least 1.3 times the maximum load induced pressure but the pressure required to open the valve and allow movement depends on the pilot ratio of the valve. For optimization of load control and energy usage, a choice of pilot ratios is available.The pressure required to open the valve and start actuator movement can be calculated as follows:Pilot Pressure = (Relief Setting) - (Load Pressure)
Features:
Cartridge is economical and fits simple cavity. Allows quick, easy field service - reduces down time. Interchangeable with pilot check valve of a similar size
Pilot ratio:
2.5:1 Best suited for extremely unstable applications such as long booms or flexible frameworks.
5:1 (standard) Best suited for applications where load varies and machine structure can induce instability.
10:1 Best suited for applications where the load remains relatively constant.
Performance data:
Figures based on: Oil Temp = 40° C Viscosity = 32 cSt (150 SUS)
Rated flow 30 L/min (8 USgpm)
Max relief pressure 350 bar (5000 psi)
Max load induced pressure 270 bar (4000 psi)
Cartridge material Working parts hardened and ground steel. External surfaces zinc plated.
Standard housing material Aluminum (up to 210 bar). Add suffix “377” for steel option.
Mounting position Unrestricted
Cavity A6610 (See Section M)
Torque cartridge into cavity 45 Nm (33 lbs ft)
Weight 1CE30 0.15 kg (0.33 lbs)
1CE35 0.41 kg (0.90 lbs)
1CEE34 0.90 kg (1.98 lbs)
Seal kits SK395 (Nitrile)
SK395V (Viton®)
Filtration Cleanliness code 18/13 (25 micron nominal)
Temperature range -30°C to +90°C (-22° to +194°F)
Internal leakage 0.3 milliliters/min nominal (5 dpm)
Nominal viscosity range 5 to 500 cSt


1CE30 - Cartridge Only
1CE35 - Cartridge in body
1CEE34 -  Cartridges in dual body
Adjustment
F - Screw adjustment
N - Fixed
Pressure range
20 - (2.5:1 and 5:1): 70-210 bar.Std setting 100 bar
(10:1): 100-210 bar.Std setting 100 bar
35 - (2.5:1 and 5:1): 100-350
bar.Std setting 210 bar
(10:1): 120-350 bar.Std setting 210 bar
Seal material
S - Buna-N
SV - Viton
Pilot ratio
2 - 2:1
5 - 5:1
10 - 10:1

Figures based on: Oil Temp = 40° C Viscosity = 32 cSt (150 SUS)
Rated flow 30 L/min (8 USgpm)
Max relief pressure 350 bar (5000 psi)
Max load induced pressure 270 bar (4000 psi)
Cartridge material Working parts hardened and ground steel. External surfaces zinc plated.
Standard housing material Aluminum (up to 210 bar). Add suffix “377” for steel option.
Mounting position Unrestricted
Cavity A6610 (See Section M)
Torque cartridge into cavity 45 Nm (33 lbs ft)
Weight 1CE30 0.15 kg (0.33 lbs)
1CE35  0.41 kg (0.90 lbs)
1CEE34 0.90 kg (1.98 lbs)
Seal kits SK395  (Nitrile)SK395V    (Viton®)
Filtration Cleanliness code 18/13 (25 micron nominal)
Temperature range -30°C to +90°C (-22° to +194°F)
Internal leakage 0.3 milliliters/min nominal (5 dpm)
Nominal viscosity range 5 to 500 cSt

1CE*** F 3W 35 S
1基本型号
1CE30 = 仅有插件
1CE35   = 单阀&阀体
1CEE34 = 双阀&阀体


2调节方式
F =  内六角螺栓调节
N = 固定方式-压力根据需
3
油口尺寸-仅对阀块体
3W = 3/8”BSP 阀口和负载口,1/4”BSP 先导口
6T = 3/8”SAE 阀口和负载口,1/4”SAE 先导口
8T = 1/2”SAE 阀口和负载口,1/4”SAE 先导口

4平衡压力范围@4.8 l/min
20 = (2.5:1 & 5:1):70-210bar.出厂设置:100bar
(10:1): 100-210bar.出厂设置:100bar
35 = (2.5:1 & 5:1):100-350bar.出厂设置:210bar
(10:1): 120-350bar.出厂设置:210bar
标准设置在 4.8l/min,可据需求提供其他压力范围

求预先设定
对于固定方式,设置的数字以 10bar 为间隔置于编
5
密封
S = 丁腈橡胶(适用于大多数工业用液压油)
SV = 氟橡胶(适用于高温和特种流体介质)
6
先导比
2 = 2.5:1
5 = 5:1(标准)
10 = 10:1

号末尾,出厂设置精度
10%。
插件尺寸

基本型号: 1CE30

内六角调节
4.0 A/F
17.0 A/F

“F”方式调整,进行调节前松开紧固螺母,调节后拧紧螺母, 紧固螺母扭矩——20 到 25Nm
“F”校准放松螺母拧紧扭矩
——20 到 25Nm


伊顿威格士EATON VICKERS液压泵PUMP
伊顿威格士EATON VICKERS液压阀Valve ,
伊顿威格士EATON VICKERS比例阀Proportional valve,
伊顿威格士EATON VICKERSIH插装阀,
伊顿威格士EATON VICKERS液压马达motor
伊顿威格士EATON VICKERS备件
上海岱仙液压设备有限公司
Shanghai DC Hydraulic Fluid Power.
电话:86-18701882843
传真:86-21-59100212
QQ:422025454
邮箱:infoshdc@126.com
联系人:陈工
www.dchydraulic.com 公司官网


上海岱仙液压设备有限公司专业经销威格士液压泵阀, 同时设计制作各种规格液压阀组,液压泵站CPU。伊顿威格士柱塞泵PVH74,PVH098,PVH131,PVQ20,4535V,3520V,35V,25V,PVXS-180,PVXS-250; 比例阀:KBFDG5V7,KBDG4V5,KBDG5V5,KBDG5V7;  DG4V3-,DG4V-5,DG5S4,DG5V-7,DGMPC-3,DGMX2-3,DGMC-3,DGMDC-3/5;  DGMFN-7,DGMPC-7;DG3VP,威格士滤芯。


公司常备现货,汽车厂,钢厂,港口造船维修。"
专业代理销售美国伊顿威格士 EATON VICKERS 液压元件,高压柱塞泵PVH074,PVH098,PVH131,PVH141,PVQ20,PVQ10,PVQ32,PVQ40,PVB系列,叶片泵3525V,25V,45V,4535V压力阀CG2V,CG5V,比例阀KBSDG,KBFDG..公司专注于机床,冶金,电力,水泥,有色金属,船舶机械等领域。完整的解决方案可以满足客户的实际需求。

EATON VICKERS伊顿威格士 1CE100P35S4
EATON VICKERS伊顿威格士 1CE100P35S8
EATON VICKERS伊顿威格士 1CE100P35SV4
EATON VICKERS伊顿威格士 1CE100P35SV8
EATON VICKERS伊顿威格士 1CE120F35S3
EATON VICKERS伊顿威格士 1CE120F35S3 280BAR
EATON VICKERS伊顿威格士 1CE120F35S8
EATON VICKERS伊顿威格士 1CE120F35SV3
EATON VICKERS伊顿威格士 1CE120F35SV8
EATON VICKERS伊顿威格士 1CE140F20S4
EATON VICKERS伊顿威格士 1CE140F20S6
EATON VICKERS伊顿威格士 1CE140F30S4
EATON VICKERS伊顿威格士 1CE140F30S6
EATON VICKERS伊顿威格士 1CE140F40S4
EATON VICKERS伊顿威格士 1CE140F40S6
EATON VICKERS伊顿威格士 1CE140-F-40SV4
EATON VICKERS伊顿威格士 1CE20F20S3
EATON VICKERS伊顿威格士 1CE20F20S4
EATON VICKERS伊顿威格士 1CE20F20S8
EATON VICKERS伊顿威格士 1CE20F35S3
EATON VICKERS伊顿威格士 1CE20F35S4
EATON VICKERS伊顿威格士 1CE20F35S8
EATON VICKERS伊顿威格士 1CE20F35SV3
EATON VICKERS伊顿威格士 1CE20-N-21S3
EATON VICKERS伊顿威格士 1CE20N27S3
EATON VICKERS伊顿威格士 1CE300F35P8
EATON VICKERS伊顿威格士 1CE300F35S3
EATON VICKERS伊顿威格士 1CE300F35S8
EATON VICKERS伊顿威格士 1CE300F35SV3
EATON VICKERS伊顿威格士 1CE300F35SV8
EATON VICKERS伊顿威格士 1CE30F10SV2
EATON VICKERS伊顿威格士 1CE30F20S10
EATON VICKERS伊顿威格士 1CE30F20S2
EATON VICKERS伊顿威格士 1CE30F20S5
EATON VICKERS伊顿威格士 1CE30F20SV10
EATON VICKERS伊顿威格士 1CE30F20SV5
EATON VICKERS伊顿威格士 1CE30F35S10
EATON VICKERS伊顿威格士 1CE30F35S2
EATON VICKERS伊顿威格士 1CE30F35S5
EATON VICKERS伊顿威格士 1CE30F35SV10
EATON VICKERS伊顿威格士 1CE30F35SV2
EATON VICKERS伊顿威格士 1CE30F35SV5
EATON VICKERS伊顿威格士 1CE30-F-7S-10
EATON VICKERS伊顿威格士 1CE30G35S5
EATON VICKERS伊顿威格士 1CE30G35SV5
EATON VICKERS伊顿威格士 1CE30N13S2
EATON VICKERS伊顿威格士 1CE30N16S25
EATON VICKERS伊顿威格士 1CE30N16S5
EATON VICKERS伊顿威格士 1CE30N18S5
EATON VICKERS伊顿威格士 1CE30N20S5
EATON VICKERS伊顿威格士 1CE30N21S2
EATON VICKERS伊顿威格士 1CE30N21S5
EATON VICKERS伊顿威格士 1CE30N23S10
EATON VICKERS伊顿威格士 1CE30N23S5
EATON VICKERS伊顿威格士 1CE30-N-24.2S-5
EATON VICKERS伊顿威格士 1CE30-N-24.5S-2
EATON VICKERS伊顿威格士 1CE30N24S10
EATON VICKERS伊顿威格士 1CE30N25S2
EATON VICKERS伊顿威格士 1CE30N25S5
EATON VICKERS伊顿威格士 1CE30N25SV2
EATON VICKERS伊顿威格士 1CE30N27S2
EATON VICKERS伊顿威格士 1CE30N27S5
EATON VICKERS伊顿威格士 1CE30N28S10
EATON VICKERS伊顿威格士 1CE30N30S2
EATON VICKERS伊顿威格士 1CE30N30S5
EATON VICKERS伊顿威格士 1CE30N32S10
EATON VICKERS伊顿威格士 1CE30N35S10
EATON VICKERS伊顿威格士 1CE30N35S5
EATON VICKERS伊顿威格士 1CE30N35SV10
EATON VICKERS伊顿威格士 1CE30N38S10
EATON VICKERS伊顿威格士 1CE30N5S2
EATON VICKERS伊顿威格士 1CE30-N-7.5S-5
EATON VICKERS伊顿威格士 1CE30N8S5
EATON VICKERS伊顿威格士 1CE90F20S3
EATON VICKERS伊顿威格士 1CE90F20S4
EATON VICKERS伊顿威格士 1CE90F20S8
EATON VICKERS伊顿威格士 1CE90F20SV4
EATON VICKERS伊顿威格士 1CE90F20SV8
EATON VICKERS伊顿威格士 1CE90F35S3
EATON VICKERS伊顿威格士 1CE90F35S4
EATON VICKERS伊顿威格士 1CE90F35S6
EATON VICKERS伊顿威格士 1CE90F35S8
EATON VICKERS伊顿威格士 1CE90F35SV4
EATON VICKERS伊顿威格士 1CE90F35SV8
EATON VICKERS伊顿威格士 1CE90G20S4
EATON VICKERS伊顿威格士 1CE90G35S4
EATON VICKERS伊顿威格士 1CE90N13.8S4
EATON VICKERS伊顿威格士 1CE90-N-16S-4
EATON VICKERS伊顿威格士 1CE90N20.7S4
EATON VICKERS伊顿威格士 1CE90N20S3
EATON VICKERS伊顿威格士 1CE90N27S3
EATON VICKERS伊顿威格士 1CE90N30S3
EATON VICKERS伊顿威格士 1CE90N35S3
EATON VICKERS伊顿威格士 1CEB120P35P3
EATON VICKERS伊顿威格士 1CEB120P35P8
EATON VICKERS伊顿威格士 1CEB120P35S3
EATON VICKERS伊顿威格士 1CEB120P35S8
EATON VICKERS伊顿威格士 1CEB120P35SV3
EATON VICKERS伊顿威格士 1CEB120P35SV8
EATON VICKERS伊顿威格士 1CEB300F35S3
EATON VICKERS伊顿威格士 1CEB300F35S8
EATON VICKERS伊顿威格士 1CEB300F35SV3
EATON VICKERS伊顿威格士 1CEB300F35SV8
EATON VICKERS伊顿威格士 1CEB30F15S5
EATON VICKERS伊顿威格士 1CEB30F17S5
EATON VICKERS伊顿威格士 1CEB30F35S2
EATON VICKERS伊顿威格士 1CEB30F35S5
EATON VICKERS伊顿威格士 1CEB30F35SV5
EATON VICKERS伊顿威格士 1CEB30N14S5
EATON VICKERS伊顿威格士 1CEB30N16S5
EATON VICKERS伊顿威格士 1CEB30N18S5
EATON VICKERS伊顿威格士 1CEB30N20S5
EATON VICKERS伊顿威格士 1CEB30N21S5
EATON VICKERS伊顿威格士 1CEB30N25S5
EATON VICKERS伊顿威格士 1CEB30N25SV2
EATON VICKERS伊顿威格士 1CEB30N27S5
EATON VICKERS伊顿威格士 1CEB30N30S5
EATON VICKERS伊顿威格士 1CEB90F20S4
EATON VICKERS伊顿威格士 1CEB90F35S13
EATON VICKERS伊顿威格士 1CEB90F35S4
EATON VICKERS伊顿威格士 1CEB90F35SV4
EATON VICKERS伊顿威格士 1CEB90G35S4
EATON VICKERS伊顿威格士 1CEB90N35S4
EATON VICKERS伊顿威格士 1CEBD120F35P22
EATON VICKERS伊顿威格士 1CEBD120F35P3
EATON VICKERS伊顿威格士 1CEBD120F35P8
EATON VICKERS伊顿威格士 1CEBD120F35S3
EATON VICKERS伊顿威格士 1CEBD120F35S8
EATON VICKERS伊顿威格士 1CEBD120F40P12
EATON VICKERS伊顿威格士 1CEBD300F35P3
EATON VICKERS伊顿威格士 1CEBD300F35P8
EATON VICKERS伊顿威格士 1CEBD300-F-35S-3
EATON VICKERS伊顿威格士 1CEBD300F35S8
EATON VICKERS伊顿威格士 1CEBD300F35SV3
EATON VICKERS伊顿威格士 1CEBD30F20S5
EATON VICKERS伊顿威格士 1CEBD30F35S5
EATON VICKERS伊顿威格士 1CEBD90-F-20S-4
EATON VICKERS伊顿威格士 1CEBD90F20SV4 OVERCENTRE CARTRIDGE
EATON VICKERS伊顿威格士 1CEBD90F35P4
EATON VICKERS伊顿威格士 1CEBD90F35S4
EATON VICKERS伊顿威格士 1CEBL151F4W35P
EATON VICKERS伊顿威格士 1CEBL151F6W35P
EATON VICKERS伊顿威格士 1CEBL153F4W35P
EATON VICKERS伊顿威格士 1CEBL256F3/4635P
EATON VICKERS伊顿威格士 1CEBL31F3W35P
EATON VICKERS伊顿威格士 1CEBL31F4W35P
EATON VICKERS伊顿威格士 1CEBL356F1635P
EATON VICKERS伊顿威格士 1CEBL356F1637P
EATON VICKERS伊顿威格士 1CEL140F30S
EATON VICKERS伊顿威格士 1CEL140F30S240/70
EATON VICKERS伊顿威格士 1CEL140F35S260/50
EATON VICKERS伊顿威格士 1CEL30F30P
EATON VICKERS伊顿威格士 1CEL30F30S240/40
EATON VICKERS伊顿威格士 1CEL30-F-30S-250/30
EATON VICKERS伊顿威格士 1CEL90F20S150/40
EATON VICKERS伊顿威格士 1CEL90F30S-220/110
EATON VICKERS伊顿威格士 1CEL90F30S-220/130
EATON VICKERS伊顿威格士 1CER140F20S4 OVERCENTRE CARTRIDGE
EATON VICKERS伊顿威格士 1CER140F20S6
EATON VICKERS伊顿威格士 1CER140F30S4
EATON VICKERS伊顿威格士 1CER140F30S6
EATON VICKERS伊顿威格士 1CER140F40S4
EATON VICKERS伊顿威格士 1CER140F40S6
EATON VICKERS伊顿威格士 1CER140-F-40SV-4
EATON VICKERS伊顿威格士 1CER30F20S4
EATON VICKERS伊顿威格士 1CER30F35P4
EATON VICKERS伊顿威格士 1CER30F35S2
EATON VICKERS伊顿威格士 1CER30F35S4
EATON VICKERS伊顿威格士 1CER30N07S4
EATON VICKERS伊顿威格士 1CER30N16S2
EATON VICKERS伊顿威格士 1CER30N21S4
EATON VICKERS伊顿威格士 1CER30-N-30S-2
EATON VICKERS伊顿威格士 1CER30N35S4
EATON VICKERS伊顿威格士 1CER90F20S4
EATON VICKERS伊顿威格士 1CER90F35S2
EATON VICKERS伊顿威格士 1CER90F35S3
EATON VICKERS伊顿威格士 1CER90F35S4
EATON VICKERS伊顿威格士 1CER90-F-35SV-4
EATON VICKERS伊顿威格士 1CER90G35S4
EATON VICKERS伊顿威格士 1CER90N35S4
EATON VICKERS伊顿威格士 1CEV30F30S5



02-112713 DPS2-10-T-S-0-40 566612 DPS2-10-F-F-0-40 02-178741 BODY STEEL 1/2 BSP C-12-4 FPR11/2-10BAR CHECK VALVE 406AA00147A 1CE30N30S5 406AA00986A 1CEBD90-F-20S-4 02-184549 VCB1-10-C-0-A-50/ 02-180439 RV8-8-C-0-50/ 565783 RV8-10-C-0-50/ 407AA00259A
02-112739 DPS2-10-F-S-0-160 566613 DPS2-10-S-F-0-40 02-180051 BODY STEEL 3/4 BSP C-10-2 FPR11/2-1BAR CHECK VALVE 406AA00148A 1CE30-N-7.5S-5 406AA00987A 1CEBD90F20SV4 OVERCENTRE CARTRIDGE 02-198363 CBV1-10-K-0-A-30/ 02-180947 PUV3-10-S-0-85-15/ 565853 RV5-10-I-0-50/ 407AA00261A
02-112750 DPS2-10-P-F-0-20 566628 DPS2-10-V-F-0-40 407AA00107A BXP240516W4WS377 SUB-ASSY FOR TWIN PUMP U FPR11/2-5BAR CHECK VALVE 406AA00149A 1CE30N8S5 406AA01034A 1CEBL151F6W35P 02-199651 CBV2-12-S-0-A-30/-A 02-181293 RV8-8-K-0-50/ 565854 RV5-16-S-0-30 407AA00270A
02-112751 DPS2-20-P-F-0-40 566636 DPS2-16-P-F-0-160 A13615 BODY STEEL 1AR65/2CR35 FPR11/4-0.5BAR CHECK VALVE 406AA00164A 1CE90F20S4 406AA01043A 1CEBL153F4W35P 02-112722 RV2-10-K-0-35/ 02-181596 RV3-10-I-0-36/28 565903 PUV3-10-S-0-85-30 407AA00271A
02-112778 DPS2-16-P-F-0-5 566642 DPS2-16-R-F-0-40 A14128 BODY STEEL 1DR2/2CN/S2 FPR11/4-10BAR CHECK VALVE 406AA00165A 1CE90F20S8 406AA01093A 1CEBL31F4W35P 02-112762 RV1-10-K-0-9/ 02-182046 RV5-16-S-0-50/ 565918 RV1-10-I-0-30/ 407AA00274A
02-112780 DPS2-16-P-S-0-5 566675 DPS2-10-T-F-0-20 A14175 BODY STEEL 3/8 SAE 1DR/2CN/7S*/S2*-6T FPR11/4-1BAR CHECK VALVE 406AA00166A 1CE90F20SV4 406AA01135A 1CEBL356F1637P 02-112828 RV5-10-C-0-3/ 02-182530 RV3-10-S-0-9/3 565919 RV2-10-I-0-50/ 407AA00275A
02-112831 DPS2-10-V-F-0-20 566687 DPS2-16-S-F-0-80 A1882 BODY STEEL 1/4 SAE 1SB15/1SH25-4T FPR11/4-4BAR CHECK VALVE 406AA00172A 1CE90N13.8S4 406AA02039A 1CEL140F30S 02-112870 RV2-10-C-0-3/ 02-182895 PUV3-10-C-0-80-15/ 565974 RV1-10-S-0-9/ 407AA00296A
02-112964 DPS2-10-P-F-0-40 566700 DPS2-16-R-F-0-160 A1883 BODY STEEL 3/8 BSP 1SB15/1SH25-6T FPR1-10BAR CHECK VALVE 406AA00177A 1CEB120P35P3 406AA02181A 1CER140F20S4 OVERCENTRE CARTRIDGE 02-112895 RV1-10-C-0-9/ 02-183045 RV4-10-F-0-50/25 565982 RV3-10-I-0-36/ 407AA00392A
02-112984 DPS2-20-P-S-0-160 889271 DPS2-10-F-S-0-80 AXP24049-8W377 SUB-ASSY STEEL ZINC FPR1-1BAR CHECK VALVE 406AA00185A 1CEB120P35SV3 406AA02183A 1CER140F40S6 02-112896 RV2-10-C-0-20/ 02-184027 RV3A-10-S-0-36/25 566014 RV8-10-K-0-25/ 407AA00433A
02-112992 DPS2-20-P-F-0-20 889272 DPS2-10-P-S-0-80 AXP24053-4WS377 SUB ASSY 4W STEEL FPR1-2.5BAR CHECK VALVE 406AA00188A 1CEB300F35SV3 406AA02208A 1CER30F20S4 02-112931 PUV3-10-S-0-75-30/ 02-184241 RV3-16-C-0-35/ 566015 RV8-10-S-0-25 407AA00468A
02-112994 DPS2-16-P-S-0-160 889273 DPS2-10-R-S-0-80 B 542 BODY STEEL 1CLLR/1LR150 FPR1-4BAR CHECK VALVE 406AA00189A 1CEB30N27S5 406AA02210A 1CER30F35P4 02-112986 RV10-10-S-0-10/ 02-198923 RV3-10-S-0-27/ 566038 RV8-10-S-0-4 407AA00477A
02-113010 DPS2-20-V-F-0-20 889275 DPS2-10-T-F-0-80 B 882 BODY STEEL 1LR350*10W FPR1-5BAR CHECK VALVE 406AA00195A 1CEB90F20S4 406AA02222A 1CER30N07S4 02-113064 RV10-10-C-0-5/ 02-199280 RV3A-10V-F-0-36/15 566039 RV3-16-S-0-13/ 407AA00494A
02-113041 DPS2-16-B-S-0-5 889276 DPS2-10-T-S-0-80 B12823 BODY STEEL 1CE*/4CK35 FPR3/4-0.5BAR CHECK VALVE 406AA00196A 1CEB90F35S13 406AA02224A 1CER30N16S2 02-113069 RV10-10-S-0-5/ 02-199852 RV1-10-S-0-36/26 566040 RV8-10-S-0-12/ 407AA00521A
02-113081 DPS2-16-T-F-0-40 889277 DPS2-10-V-S-0-80 B13473 BODY STEEL 1AR66*4W FPR3/4-10BAR CHECK VALVE 406AA00202A 1CEBD90F35S4 406AA02226A 1CER30N21S4 02-113128 RV1-10-S-0-18/10 02-199856 SRV4-12N-0-00030000000000000A 566212 RV2-10-S-0-35/ 407AA00525A
02-113096 DPS2-16-S-S-0-40 889279 DPS2-16-B-F-0-40 B13483 BODY STEEL 1PA66*4W FPR3/4-1BAR CHECK VALVE 406AA00247A-H 1CEL90F30S-220/130 406AA02228A 1CER30-N-30S-2 02-113164 PUV3-10-S-0-80-30 02-200394 RV1-10-S-0-36/ 566246 RV5-10-S-0-35/ 407AA00651A
02-113125 DPS2-10-B-S-0-40 889283 DPS2-16-F-F-0-80 B13520 BODY STEEL 3/8 BSP 1PA/1PS66*3W FPR3/4-2.5BAR CHECK VALVE 406AA00251A 1CER140F40S4 406AA02230A 1CER30N35S4 02-151001 RV5-3681 02-200395 RV1-10-K-0-36/ 566260 RV1-10-I-0-18/ 407AA00708A
02-113152 DPS2-16-P-F-0-20 889284 DPS2-16-P-F-0-40 B13522 BODY STEEL 1/2 BSP 1PAA65/1HSH25 FPR3/4-4BAR CHECK VALVE 406AA00254A 1CER90F20S4 406AA02272A 1CER90F35S3 02-153226 RV2-10-K-0-20/ 02-200708 RV3-16-S-0-5/ 566295 RV4-10-F-0-50/ 407AA00716A
02-113155 DPS2-10-S-F-0-5 889285 DPS2-16-P-S-0-80 B13603 BODY STEEL 1RDS303 FPR3/4-5BAR CHECK VALVE 406AA00256A 1CER90F35S2 406AA02281A 1CER90G35S4 02-153230 RV1-10V-S-0-18/ 02-200709 RV3-16-K-0-5/ 566319 RV8-10-K-0-12/ 407AA00717A
02-113158 DPS2-10-F-F-0-20 889286 DPS2-16-R-F-0-80 B13626 BODY STEEL 1/2 BSP 1CE*/4CK95-4W FPR3/8-0.5BAR CHECK VALVE 406AA00273A 1CPBD300F2SV 406AA02291A 1CER90N35S4 02-153231 RV5-10-K-0-20/ 02-201076 RV1-10-S-0-36/23.5 566361 RV1-10-K-0-3/ 407AA00718A
02-151006 DPS2-10-T-F-0-160 889288 DPS2-16-T-F-0-80 B13663 BODY STEEL 2CFRC65*4W FPR3/8-10BAR CHECK VALVE 406AA00310A 1SE30N34.5S5 406AA02400A 1CPB30F2S 02-160655 RV10-10-C-0-2/ 301AA00015A RCV3-10V-P-000-020-00 566387 PUV3-10-S-0-90-30/ 407AA00777A
02-151021 DPS2-10-R-F-0-40 889290 DPS2-16-T-S-0-80 B13664 BODY STEEL 2CFP65*4W FPR3/8-1BAR CHECK VALVE 406AA00314A 1SE90F35S6 406AA02401A 1CPB30F2SV 02-160662 RV3-16V-S-0-50/ 307AA00030A RV1-12-S-0-2.5/ 566450 RV1-10-S-0-3/ 407AA00778A
02-153254 DPS2-20-T-F-0-40 889291 DPS2-16-V-F-0-160 B13803 BODY STEEL 1CEE*/4CKK34 FPR3/8-2.5BAR CHECK VALVE 406AA00318A 1SE90N27.5S4 406AA02409A 1CPB90F2P 02-161081 RV8A-10-C-0-25 307AA00031A RV1-12-S-0-8.5/ 566541 RV3-10-S-0-6/ 407AA00828A
02-153256 DPS2-20-S-F-0-40 889292 DPS2-16-V-F-0-20 B13838 BODY STEEL 3/8 BSP 1PD25/1RDS&SB252-3W FPR3/8-5BAR CHECK VALVE 406AA00331A 1SEL30F20S 406AA02424A 1CPBD120F2SV 02-161579 PUV3-10-C-0-85-15/ 307AA00032A RV1-12-S-0-22/ 566567 RV8-10-C-0-25 407AA00834A
02-153263 DPS2-16-V-F-0-5 889293 DPS2-16-V-F-0-40 B17070 BODY STEEL 1PA65*3W 406AA00001A 1CE20F35S3 406AA00332A 1SEL30F30S 406AA02425A 1CPBD120F4P 02-163842 RV5-10V-S-0-35/ 307AA00033A RV1-12-S-0-40/ 566577 PUV3-10-C-0-90-30/ 407AA00840A
02-153298 DPS2-10-R-F-0-160 889298 DPS2-20-P-F-0-5 B19747 BODY STEEL 1CEE/4CKK33 3W 406AA00002A 1CE20F35S4 406AA00342A 1SEL90G30S-240/60-HA 406AA02434A 1CPBD120G2P 02-163868 RV3-10-S-0-36/14 307AA00035A RV3-12-S-0-8.5/ 566593 RV2-10-C-0-35/ 407AA00847A
02-160668 DPS2-16-V-S-0-160 889302 DPS2-20-S-S-0-80 B20106 BODY STEEL 1CEL/1CER145 6W  3 406AA00003A 1CE20F35S8 406AA00344A 1SER30F35S2 406AA02441A 1CPBD30F2SV 02-163883 RV5A-10-S-0-20 307AA00036A RV3-12-S-0-22/ 566616 RV1-10-C-0-3/ 407AA00850A
02-161007 DPS2-10V-P-F-0-160 889303 DPS2-20-T-F-0-80 B20108 BODY STEEL 1CEL/1CER145 8W  1 406AA00004A 1CE30F35S2 406AA00352A 1CE30F20SV5 406AA02442A 1CPBD30G2P 02-163912 RV5-10V-C-0-50/ 307AA00037A RV3-12-S-0-40/ 566626 RV5-10-C-0-35/ 407AA00895A
02-161044 DPS2-16V-V-F-0-80 889304 DPS2-20-T-S-0-80 B20520 BODY STEEL 1DDR35-3W-377 406AA00005A 1CE30F35S5 406AA00353A 1CE30F20S10 406AA02732A 1CE20F20S4 02-163926 RV1-10-S-0-36/33 307AA00039A RV8-12-S-0-12/ 566641 RV5-16-K-0-30 407AA00967A
02-161160 DPS2-16-P-S-0-20 889305 DPS2-20-V-F-0-40 B20599 BODY STEEL 1CLLR50/S5** 406AA00006A 1CE30F35S10 406AA00356A 1CEB90N35S4 406AA02741A 1CE30N16S25 02-163964 RV3A-10-S-0-36/27.5 307AA00040A RV8-12-S-0-25/ 566654 PUV3-10-C-0-75-30 407AA00970A
02-161177 DPS2-10V-F-F-0-80 889306 DPS2-20-V-F-0-5 B22262 BODY STEEL S717 6W 406AA00007A 1CER30F35S2 406AA00359A 1SE30F20S5 406AA02742A 1CE30N24S10 02-163967 RV3-10-C-0-3/ 307AA00041A RV8-12-S-0-50/ 566674 RV5-16-C-0-30 407AA00971A
02-161181 DPS2-16-T-S-0-40 402AA00470A LER202N1-02 B23886 BODY STEEL 1HSH26 4W 406AA00008A 1CER30F35S4 406AA00361A 1CEBD300F35S8 406AA02747A 1CE90F35SV4 02-163978 RV3-10-S-0-36/29.5 307AA00258A RV3-10V-S-0-36/30.5 566676 RV2-10-I-0-35/ 407AA01017A
02-161286 DPS2-10V-P-F-0-5 402AA00471A LER202N2-02 B23895 BODY STEEL 1HSH756 6W 406AA00009A 1CEB30F35S2 406AA00363A 1CE30N35S5 406AA02748A 1CE90F35SV8 02-164028 RV1-10-S-0-30/20 307AA00324A RV2-10-I-0-35/26 566688 RV3-10-S-0-3/ 407AA01021A
02-161420 DPS2-20V-T-S-0-80 402AA00472A LER202V1-02 B24062 BODY STEEL LER252 8W 406AA00010A 1CEB30F35S5 406AA00379A 1CE30N27S2 406AA02901A 1CEV30F30S5 02-164032 RV3-10-K-0-3/ 307AA00357A RV5-10-S-0-35/17 889505 PUV3-10-C-0-80-30/ 407AA01023A
02-161429 DPS2-20-V-F-0-160 402AA00485A LER402N2-1.0S B24254 BODY STEEL 1CE25 406AA00013A 1CPB30F2P 406AA00391A 1SE140F20S4 406AA02952A 1CEL140F35S260/50 02-164140 RV5A-10-S-0-35/ 307AA00380A RV3-10V-F-0-36/30 889506 PUV3-10-C-0-85-30 407AA01024A
02-161434 DPS2-20-S-F-0-5 402AA00525A LER402N2-0.4S B24260 BODY STEEL 1CEE24 3/8BSP 406AA00014A 1CPBD30F2P 406AA00395A 1SE30F20S10 406AA02992A 1CEL30F30P 02-164146 RV5-16V-S-0-60/ 307AA00412A RV1-10-F036/30.5 889540 RV2-10-S-0-20/ 407AA01025A
02-161439 DPS2-20-B-F-0-40 02-112703 DSV4-10-O-0-40 B3497 BODY STEEL 1PA/PS/VR250 406AA00015A 1CE90F35S3 406AA00404A 1SE30F7S10 406AA02999A 1CPBD120-F-P-22 02-164149 RV5-16V-S-0-30/ 307AA00414A RV1-10-I-0-36/ 889541 RV2-10-S-0-3/ 407AA01046A
02-161452 DPS2-16-S-F-0-40 02-112808 DSV1-10V-B-0 B4376 BODY STEEL 1DS/1PA/1*PS3W ST 3/8BSP 406AA00016A 1CE90F35S4 406AA00411A 1SE30N35S10 406AA03011A 1CE20-N-21S3 02-164181 RV5-10V-S-0-50/ 307AA00436A RV3-10-C06/5.8 889550 RV3-10-I-0-18/ 407AA01050A
02-161455 DPS2-16-P-S-0-40 02-113145 DSV4-10-C-0-160 B4378 BODY STEEL 3/4 BSP 1VR150/1PF55-6W 406AA00017A 1CE90F35S6 406AA00420A 1SE90F35S3 406AA03027A 1CER140-F-40SV-4 02-164253 RV5-10-C-0-20/ 307AA00452A RV5-16-S-0-60/29.7 889554 RV3-10-I-0-6/ 407AA01100A
02-161467 DPS2-10-V-F-0-160 02-162392 DSV2-4-B-000-01 B4403 BODY STEEL 3/4 BSP 1DS/1PA/1*PS*-6W 406AA00018A 1CE90F35S8 406AA00424A 1SEB30F10S5 406AA03029A 1CER90-F-35SV-4 02-164261 RV3A-10-S-0-36/ 307AA00460A RV5-10-F-0-3/2.5 889562 RV5-10-I-0-3/ 407AA01120A
02-161473 DPS2-10-P-F-0-5 02-165572 DSV4-16-C-0-160 B4527 BODY STEEL 1DS/1PA/1PS* 406AA00019A 1CER90F35S4 406AA00429A 1SEB90F20S4 406AA03031A 1CE30N30S2 02-164273 RV3-16V-S-0-35/ 307AA00578A RV2-10-S-0-35/26 889563 RV5-10-I-0-35/ 407AA01124A
02-161620 DPS2-10-V-F-0-10 02-165573 DSV4-16V-C-0-40 B4596 BODY STEEL 1*AR*/1GR155 406AA00020A 1CEB90F35S4 406AA00431A 1SEL140F30S 406AA03035A 1CE20F35SV3 02-164291 RV3-16-K-0-50/ 307AA00583A RV3-10-F-0-36/28.3 889566 RV5-10-S-0-20/ 407AA01129A
02-161755 DPS2-20V-V-F-0-80 02-171239 DSV2-8-B-0 B5544 BODY STEEL 1CE*/4CK 406AA00022A 1CPBD90F2P 406AA00432A 1SEL140F40S290/60 406AA03042A 1CE30N38S10 02-164294 RV3-16-K-0-13/ 407AA00003A 1GR30P7S 889567 RV5-10-S-0-3/ 407AA01130A
02-161756 DPS2-20V-V-F-0-20 02-171952 DSV4-16-0-0-160 B5614 BODY STEEL 1CLLR/1LR150 406AA00023A 1CE120F35S3 406AA00433A 1SEL30F40S 406AA03052A 1CEL140F30S240/70 02-164296 RV3-10V-S-0-9/ 407AA00004A 1GR30P14S 889583 RV8-10-I-0-50/ 407AA01158A
02-161764 DPS2-20-B-S-0-40 02-176523 DSV2-8V-B-0 B7147 BODY STEEL 1CLLR/1LR155 406AA00024A 1CE120F35S8 406AA00435A 1SEL30G40S 406AA03061A 1CEL90F20S150/40 02-164301 RV3-10V-S-0-36/ 407AA00005A 1GR100P0.6S 02-163950 VRV11-12-S-0-15/ 407AA01623A
02-161788 DPS2-10-F-S-0-40 02-182304 DSV3-12V-B-S-4 B8610 BODY STEEL 1CE*/4CK350-10W 1 1/4 BSP 406AA00025A 1CPBD120F2P 406AA00439A 1SEL90F30S 406AA03062A 1SEL30F30S-220/50 02-164304 RV3-10V-S-0-3/ 407AA00006A 1GR100P4S 02-164617 VRV11-12-S-0-30/ 407AA01708A
02-161813 DPS2-20-S-F-0-20 02-199239 DSV2-4-B-000-00 B8627 BODY STEEL 2CFD454W3W 406AA00026A 1CE140F30S4 406AA00447A 1SER30F20S4 406AA03072A 1CE120F35S3 280BAR 02-164344 RV3-10-S-0-36/26 407AA00007A 1LR300F20S 02-164778 VRV11-12-C-0-30/ 407AA01710A
02-161888 DPS2-16-F-S-0-160 02-201125 DSV2-8-B-0-ASV5-8-C/CM SV15-8-C/CM  SBV11-8-C SBV12-8-C
SV1-10-C/CM/CR SV11-10-C/CM SV11-10-C/CM
SBV11-10-C SV2-10-C/CM/CR SV12-10-C/CM/CR
SV3-10-C/CM/CR SV13-10-C/CM/CR SV13-20-C/CM/CR
SV3-12-C/CM/CR SV13-12-C/CM/CR SBV11-12-C
SV1-16-C/CM/CR SV13-16-C/CM/CR SV2-20-C/CM/CR
SV4-8-C/CM SV14-8-C/CM SV4-10-C/CM/CR SV14-10-C/CM/CR
SV5-8-O/OP/OS SV15-8-O/OP/OS SBV11-8-O
SV3-10-O/OP/OS SV13-10-O/OP/OS SV5-10-O/OP/OS
SV15-10-O/OP/OS SBV11-10-O/OP/OS SV3-12-O/OP/OS
SV13-12-O/OP/OS SBV11-12-O/OP/OS SV3-16-O/OP/OS
SV13-16-O/OP/OS SV3-20-O/OP/OS SV13-20-O/OP/OS
SV4-8-O/OM SV14-8-O/OM SV4-10-O/OM/OR SV14-10-O/OM/OR
SV1-8-3/3M.SV11-8-3/3M SV4-8-3/3M SV1-10-3/3M/3R
SV11-10-3/3M/3R SV4-10-3/3P/3S SV1-8-4/4M
SV11-8-4/4M SV2-8-4/4M SV12-8-4/4M SV1-10-4/4M/4R
SV11-10-4/4M/4R SV2-10-4/4M/4R SV3-10-4/4M/4R
SV4-10-4/4M/4R SV5-10-4/4M/4R SV7-10-4/4P/4S
SV9-8*0/8*M SV9-10*0/10*M


FPR1/4 FPR3/8 FPR1/2 FPR3/4 FPR1 FPR11/4 FPR11/2
3CA20 CV3-4 CV3-8  CV3-10 CV13-10 CV11-12
CV1-16 CV11-16 CV11-16 CV2-20 3CA300 CV16-10 CV6-10 CV6-16 SPC2-8 SPC2-10
4CK30 4CK90 4CKD90 4CK120 4CK300 4SK30 4SK90 4SK140 4KD25
DPC2-8 5CK30 5CK120 5CK300 1SH10 1SH60 DSV1-10 DSV2-4  DSV2-8 DSV3-XX-B
FPR 3CA  4CK 5CK CV1 CV2 CV3 SPC2 DSV 1SH


DPS2-8 DPS2-10 DPS2-12 DPS2-16 DPS2-20 LE402 LEV402

MRV4-10 MRV14-10 MRV14-12 MRV4-16
MRV5-10 MRV15-10 MRV15-12 MRV5-16
MRV6-10 MRV6-16 MRV7-10 MLV9-12-A
MLV9-12-E MLV9-12-F 3CP2 MPV1-10
MSV1-12 MSV11-10 MSV11-12 MSV12-12
MSV5-12 MSV15-12 MSV3-12 MSV13-12
MSV6-12 MSV16-12 MSV17-10 MSV7-12
PTS7-10 PTS17-10 PTS17-12 1RDS702
PTS1-10 PTS11-12 PTS11-10 PTS1-16
PTS1-20 PTS12-10 PTS12-12 PTS2-16
PTS2-20 PTS13-10 PTS13-12 PTS3-16
PTS3-20 PTS6-16 PTS16-16 PTS14-12
PTS5-16 PTS15-16 PTS5-10 PTS5-12 PTS9-8
PTS9-10 PTS9-12 PTS9-16 PTS9-20 1HSH20
DSV4-10 DSV4-12 DSV4-16 1HSH701
PTS16-10 PTS16-12 MRV14-16 MRV15-16
MLV9-12-B MPV3-10 MSV2-12 MSV17-12
MSV4-12 MSV14-12 1SB10 1SB304
PTS11-16 PTS12-16 PTS13-16 PTS14-16


1CE20 1CE30 1CER30 1CEB30 1CEL30 1CPB30 1CPBD30 1CE90
1CER90 1CEB90 1CEBD90 1CE120 1CEBD120 1CE140 1CER140
1CEL140 1CE300 1CEBD300 1CPBD300
CBV1-10 CBV1-12 CBV2-10 CBV2-12 VCB1-10 VCB1-12


1DR2 1DR30 RV1-10 RV1-12 RV5-10 RV11-12 1AR100
RV5-16 RV4-10 RV2-10 1ARC100 RV8-8 RV3-10 RV8-10
RV3-12 RV8-12 RV3-16 1LR300 1ARD100 1GR30 1GR60 1GR100
1VR100 1VR200 1UL60 1PUL60 1PUL200 1CLLR50 1CLLR100
PSV2-8 PSV4-8 PSV2-10 PSV4-10 PSV8-10 PSV10-10 PSV1-10
PSV5-10 PSV3-10 PSV7-10 1DS30 1DS60 1DS100 1PS60 1PS100
1PS200 PSV11-16 PSV1-16 1PSC30 1PSC100 1UPS100
PUV3-10 ADV1-16 PRV1-10 PRV2-10 PRV12-10 PRV12-12
PRV2-16 1PA100 1PA200 1PDC5
B9075 BODY STEEL 2CFD250 10W 406AA00027A 1CE140F30S6 406AA00454A 1SER90F35S6 406AA03076A 1CEL90F30S-220/110 02-164383 RV3-10-I-0-36/27 407AA00008A 1LR300F35S 02-173229 RV1-8-S-0-3/ 407AA01723A
02-171003 DPS2-20-R-F-0-40 402AA00063A 1SB10S BXP13634-6WS377 SUB ASSY 1CEG150 406AA00028A 1CER140F30S4 406AA00516A 1CE100P35SV4 406AA03084A 1SEL30F20S200/70
Copyright 上海岱仙液压液压设备有限公司 Mail:infoshdc@126.com Tel:86-18701882843
网站备案号:沪ICP备05008530号
展开
